AX Pro DS-PM1-I16O2-WE | Peripheral
Specifications
- End of Line Resistance: 1k 2.2k 4.7k 8.2k NO/NC
- Serial port: 1
- Battery port: 1, 12 VDC input
- Tamper-Proof: Front and rear
- Power switch: 1
- Alarm input: 16
- Alarm output: 2
- Power Output: 2 (12v, total1A)
- Indicator: 3: Power（Green）, Fault（Amber）, Signal Strength（Green/Red）
- Battery type: Compatible with 12v 7 Ah 150 × 64 × 94 mm
- Power supply: 100-240VAC，30w
- Operation humidity: 10%~90%
- Operation temperature: –10 ~ 40°C
- Power consumption: Battery Supply: Quiescent current (50mA), Max current (1500mA), Voltage (13.8V) 220V Supply: Quiescent current (45mA), Max current (300mA), Voltage (220V)
- Battery life span: Up to 36 hours
- RF frequency: 868MHz
- RF method: Two-way communication
- RF modulation: 2GFSK
- RF distance: 1100m
- Installation method: Wall Mounting
- Dimension(WxHxD): 261*199*86.4mm
- Shell material: Plastic
- Color: White
- Weight: 975 g (without battery) 3024g (with battery)
