Hikvision DS-2CD6425G2-C2 2MP Pinhole Camera Covert Modular Unit

Hikvision DS-2CD6425G2-C2 2MP Pinhole Camera Covert Modular Unit

Category: IP CCTV
|
Brand: Hikvision
  • IP CCTV
  • 2MP
  • Fixed Lens
  • 40 years of Trust
  • Free Delivery
  • Free Returns
  • Expert Tech Support
View full details
Hikvision DS-2CD6425G2-C2 2MP Pinhole Camera Covert Modular Unit
Login to View Price

Specifications

  • Image Sensor: 1/2.7" Progressive Scan CMOS
  • Max. Resolution: Channel 1: 1920 × 1080; Channel 2: 1920 × 1080
  • Min. Illumination: Color: 0.005 Lux @ (F1.2, AGC ON)
  • Shutter Time: 1 s to 100,000 s
  • Focal Length & FOV: L10 model:3.7 mm, horizontal FOV 77.5°, vertical FOV 39.4°, diagonal FOV 94.1°L20 model:2.8 mm, horizontal FOV 93.8°, vertical FOV 51.7°, diagonal FOV 109.3°3.7mm, horizontal FOV 77.5°, vertical FOV 39.4°, diagonal FOV 94.1°L30 model:2.8 mm, horizontal FOV 109.0°, vertical FOV 60.0°, diagonal FOV 128.3°4 mm, horizontal FOV 82.8°, vertical FOV 45.1°, diagonal FOV 98°
  • Lens Mount: L10/L20: Mini; L30: M12
  • Iris Type: Fixed
  • Aperture: F2.0
  • DORI: L10/L20:2.8 mm: D: 47.9 m, O: 19 m, R: 9.6 m, I: 4.8 m3.7 mm: D: 59.3 m, O: 23.5 m, R: 11.9 m, I: 5.9 mL30:2.8 mm: D: 41 m, O: 16 m, R: 8 m, I: 4 m4 mm: D: 55.2 m, O: 21.9 m, R: 11 m, I: 5.5 m
  • Main Stream: 50 Hz: 50 fps (1920 × 1080, 1280 × 960, 1280 × 720)60 Hz: 60 fps (1920 × 1080, 1280 × 960, 1280 × 720)
  • Sub-Stream: 50 Hz: 25 fps (704 × 576, 640 × 480)60 Hz: 30 fps (704 × 480, 640 × 480)
  • Third Stream: 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480)60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480)
  • Video Compression: Main stream: H.265/H.264,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264
  • H.264 Type: Baseline Profile,Main Profile,High Profile
  • H.265 Type: Main Profile
  • Bit Rate Control: CBR,VBR
  • Scalable Video Coding (SVC): H.264 and H.265 encoding
  • Region of Interest (ROI): 4 fixed regions for each stream
  • Protocols: TCP/IP, SRTP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
  • Simultaneous Live View: Up to 20 channels
  • API: Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
  • User/Host: Up to 32 users3 user levels: administrator, operator, and user
  • Security: Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
  • Network Storage: NAS (NFS, SMB/CIFS)
  • Client: iVMS-4200,Hik-Connect
  • Web Browser: Plug-in required live view: IE11,Plug-in free live view: Safari 12+,Local service: Chrome 57.0+, Firefox 52.0+
  • Image Parameters Switch: Yes
  • Image Settings: Rotate mode,saturation,brightness,contrast,adjustable by client software or web browser
  • Wide Dynamic Range (WDR): 120 dB
  • Image Enhancement: BLC,HLC,3D DNR,Defog
  • Privacy Mask: Yes
  • Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
  • On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
  • Reset Key: Yes
  • Basic Event: Motion detection, video tampering alarm, exception (HDD full, HDD error, network disconnected), video quality diagnosis
  • Smart Event: Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)),audio exception detection
  • Linkage: Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning
  • Power: 12 VDC ± 20%, 0.53 A, max. 6.4 W,PoE: IEEE 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.13 A, max. 7.4 W
  • Dimension: 105 mm × 78 mm × 26 mm (4.13" × 3.1" × 1.02")
  • Package Dimension: Kit/Main body: 219 mm × 139 mm × 60 mm (8.6 × 5.5\" × 2.4\")"
  • Weight: Main body: approx. 180 g (0.39 lb.)
  • With Package Weight: Package: approx. 383 g (0.84 lb.)
  • Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Startup and Operating Conditions: -30 °C to 50 °C (-22 °F to 122 °F). Humidity 95% or less (non-condensing)
  • Language: 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
  • General Function: Heartbeat,mirror,password protection,one-key reset
  • EMC: FCC: 47 CFR Part 15, Subpart B,CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,RCM: AS/NZS CISPR 32: 2015,IC: ICES-003: Issue 7,KC: KN32: 2015, KN35: 2015
  • Safety: CB: IEC 62368-1: 2014+A11,CE-LVD: EN 62368-1: 2014/A11: 2017,BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,LOA: IEC/EN 60950-1
  • Environment: CE-RoHS: 2011/65/EU,WEEE: 2012/19/EU,Reach: Regulation (EC) No 1907/2006
  • Open Resources: Memory: 60 MB,Smart RAM: 375 MB,eMMC: 2 GB
  • Computing Power: 4 TOPS
  • Deep Learning Structure: Caffe,PyTorch,TensorFlow
  • Programming Language: C,C++
  • Target Cropping: Yes
  • Audio Type: Mono sound
  • Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3
  • Audio Bit Rate: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)/8 to 320 Kbps (MP3)
  • Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
  • Environment Noise Filtering: Yes
  • Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.
  • Audio: 1 input (line in), 1 output (line out)
  • Alarm: 2 inputs, 1 output (max. 12 VDC, 30 mA)
  • RS-485: 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
  • USB: 1 micro USB 2.0 interface
  • Power Output: 12 VDC, max. 200 mA
  • Material: Main body: Aluminum Alloy+PC
  • Length of Lens Cable: 2 and 8 m (6.6 and 26.2 ft.)

Camera
  • Image Sensor: 1/2.7" Progressive Scan CMOS
  • Max. Resolution: Channel 1: 1920 × 1080; Channel 2: 1920 × 1080
  • Min. Illumination: Color: 0.005 Lux @ (F1.2, AGC ON)
  • Shutter Time: 1 s to 100,000 s

Lens
  • Focal Length & FOV: L10 model:3.7 mm, horizontal FOV 77.5°, vertical FOV 39.4°, diagonal FOV 94.1°L20 model:2.8 mm, horizontal FOV 93.8°, vertical FOV 51.7°, diagonal FOV 109.3°3.7mm, horizontal FOV 77.5°, vertical FOV 39.4°, diagonal FOV 94.1°L30 model:2.8 mm, horizontal FOV 109.0°, vertical FOV 60.0°, diagonal FOV 128.3°4 mm, horizontal FOV 82.8°, vertical FOV 45.1°, diagonal FOV 98°
  • Lens Mount: L10/L20: Mini; L30: M12
  • Iris Type: Fixed
  • Aperture: F2.0

DORI
  • DORI: L10/L20:2.8 mm: D: 47.9 m, O: 19 m, R: 9.6 m, I: 4.8 m3.7 mm: D: 59.3 m, O: 23.5 m, R: 11.9 m, I: 5.9 mL30:2.8 mm: D: 41 m, O: 16 m, R: 8 m, I: 4 m4 mm: D: 55.2 m, O: 21.9 m, R: 11 m, I: 5.5 m

Video
  • Main Stream: 50 Hz: 50 fps (1920 × 1080, 1280 × 960, 1280 × 720)60 Hz: 60 fps (1920 × 1080, 1280 × 960, 1280 × 720)
  • Sub-Stream: 50 Hz: 25 fps (704 × 576, 640 × 480)60 Hz: 30 fps (704 × 480, 640 × 480)
  • Third Stream: 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480)60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480)
  • Video Compression: Main stream: H.265/H.264,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264
  • H.264 Type: Baseline Profile,Main Profile,High Profile
  • H.265 Type: Main Profile
  • Bit Rate Control: CBR,VBR
  • Scalable Video Coding (SVC): H.264 and H.265 encoding
  • Region of Interest (ROI): 4 fixed regions for each stream
  • Protocols: TCP/IP, SRTP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
  • Simultaneous Live View: Up to 20 channels
  • API: Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
  • User/Host: Up to 32 users3 user levels: administrator, operator, and user
  • Security: Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
  • Network Storage: NAS (NFS, SMB/CIFS)
  • Client: iVMS-4200,Hik-Connect
  • Web Browser: Plug-in required live view: IE11,Plug-in free live view: Safari 12+,Local service: Chrome 57.0+, Firefox 52.0+

  • Image Parameters Switch: Yes
  • Image Settings: Rotate mode,saturation,brightness,contrast,adjustable by client software or web browser
  • Wide Dynamic Range (WDR): 120 dB
  • Image Enhancement: BLC,HLC,3D DNR,Defog
  • Privacy Mask: Yes

Interface
  • Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
  • On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
  • Reset Key: Yes

Event
  • Basic Event: Motion detection, video tampering alarm, exception (HDD full, HDD error, network disconnected), video quality diagnosis
  • Smart Event: Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)),audio exception detection
  • Linkage: Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning

General
  • Power: 12 VDC ± 20%, 0.53 A, max. 6.4 W,PoE: IEEE 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.13 A, max. 7.4 W
  • Dimension: 105 mm × 78 mm × 26 mm (4.13" × 3.1" × 1.02")
  • Package Dimension: Kit/Main body: 219 mm × 139 mm × 60 mm (8.6 × 5.5\" × 2.4\")"
  • Weight: Main body: approx. 180 g (0.39 lb.)
  • With Package Weight: Package: approx. 383 g (0.84 lb.)
  • Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Startup and Operating Conditions: -30 °C to 50 °C (-22 °F to 122 °F). Humidity 95% or less (non-condensing)
  • Language: 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
  • General Function: Heartbeat,mirror,password protection,one-key reset

Approval
  • EMC: FCC: 47 CFR Part 15, Subpart B,CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,RCM: AS/NZS CISPR 32: 2015,IC: ICES-003: Issue 7,KC: KN32: 2015, KN35: 2015
  • Safety: CB: IEC 62368-1: 2014+A11,CE-LVD: EN 62368-1: 2014/A11: 2017,BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,LOA: IEC/EN 60950-1
  • Environment: CE-RoHS: 2011/65/EU,WEEE: 2012/19/EU,Reach: Regulation (EC) No 1907/2006

Other
  • Open Resources: Memory: 60 MB,Smart RAM: 375 MB,eMMC: 2 GB
  • Computing Power: 4 TOPS
  • Deep Learning Structure: Caffe,PyTorch,TensorFlow
  • Programming Language: C,C++
  • Target Cropping: Yes
  • Audio Type: Mono sound
  • Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3
  • Audio Bit Rate: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)/8 to 320 Kbps (MP3)
  • Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
  • Environment Noise Filtering: Yes
  • Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.
  • Audio: 1 input (line in), 1 output (line out)
  • Alarm: 2 inputs, 1 output (max. 12 VDC, 30 mA)
  • RS-485: 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
  • USB: 1 micro USB 2.0 interface
  • Power Output: 12 VDC, max. 200 mA
  • Material: Main body: Aluminum Alloy+PC
  • Length of Lens Cable: 2 and 8 m (6.6 and 26.2 ft.)
