Hikvision DS-2CD6825G0/C-IS(2mm)(B) Dual-Lens People Counting IP Camera CCTV

Hikvision DS-2CD6825G0/C-IS(2mm)(B) Dual-Lens People Counting IP Camera CCTV

Category: IP CCTV
|
Brand: Hikvision
  • IP CCTV
  • 2MP
  • 40 years of Trust
  • Free Delivery
  • Free Returns
  • Expert Tech Support
View full details
Hikvision DS-2CD6825G0/C-IS(2mm)(B) Dual-Lens People Counting IP Camera CCTV
Login to View Price

Specifications

  • Image Sensor: 1/2.7" Progressive Scan CMOS
  • Max. Resolution: 2560 x 1440
  • Min. Illumination: Colour: 0.0176 Lux @ (F2.25, AGC ON),B/W: 0.0035 Lux @ (F2.25, AGC ON), B/W: 0 Lux with IR
  • Shutter Time: 1/25 s to 1/100,000 s
  • Day & Night: IR cut filter
  • Lens Type: Fixed focal lens, 2 mm
  • Focal Length & FOV: 2 mm, horizontal FOV 104.5°, vertical FOV 70.5°, diagonal FOV 112°
  • Lens Mount: M12
  • Aperture: F2.25
  • Supplement Light Type: IR
  • Supplement Light Range: Up to 6 m
  • IR Wavelength: 850 nm
  • Main Stream: 50 Hz: 25 fps (2560 x 1440, 1920 x 1080, 1280 x 720)60 Hz: 30 fps (2560 x 1440, 1920 x 1080, 1280 x 720)
  • Sub-Stream: 50 Hz: 25 fps (704 x 576, 640 x 480)60 Hz: 30 fps (704 x 480, 640 x 480)
  • Video Compression: Main stream: H.265+/H.265/H.264+/H.264,Sub-stream: H.265/H.264/MJPEG
  • Video Bit Rate: 32 Kbps to 8 Mbps
  • H.264 Type: Baseline Profile, Main Profile, High Profile
  • H.265 Type: Main Profile
  • Scalable Video Coding (SVC): H.264 and H.265 encoding
  • Region of Interest (ROI): 4 fixed region(s) for main stream and sub-stream
  • Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
  • Simultaneous Live View: Up to 20 channels
  • API: Open Network Video Interface (Profile S, Profile G),ISAPI,SDK
  • User/Host: Up to 32 users3 user levels: administrator, operator, and user
  • Security: Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.3, host authentication (MAC address)
  • Client: iVMS-4200,Hik-Connect
  • Web Browser: Plug-in required live view: IE 10, IE 11,Plug-in free live view: Chrome 57.0+, Firefox 52.0+,Local service: Chrome 57.0+, Firefox 52.0+, Safari12+
  • Image Settings: Saturation, brightness, contrast, sharpness, adjustable by client software or web browser
  • Day/Night Switch: Day, Night, Auto, Schedule, Alarm Trigger (-S)
  • Wide Dynamic Range (WDR): 120 dB
  • Image Enhancement: BLC,HLC,3D DNR, defog
  • Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
  • On-Board Storage: Built-in eMMC storage, up to 8 GB for people counting data
  • Basic Event: Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
  • Linkage: Upload to FTP/NAS/memory card, notify surveillance centre, send email, trigger recording, trigger capture
  • Power: 12 VDC ± 20%, 0.58 A, max. 7.0 W,Ø5.5 mm coaxial power plug, reverse polarity protection,PoE: 802.3af, Type 1, Class 3, 36 V to 57 V, 0.24 A to 0.15 A, max. 8.5 W
  • Dimension: 168 mm x 61 mm x 36 mm (6.6" x 2.4" x 1.4")
  • Package Dimension: 235 mm x 120 mm x 125 mm (9.2" x 4.7" x 4.9")
  • Weight: Approx. 340 g (1 lb.)
  • With Package Weight: Approx. 695 g (1.6 lb.)
  • Storage Conditions: -30 °C to 60 °C (-22 °F to 144 °F). Humidity 95% or less (non-condensing)
  • Startup and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Language: 32 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
  • General Function: Heartbeat, anti-flicker, mirror, password protection
  • EMC: FCC: 47 CFR Part 15, Subpart B,IC: ICES-003: Issue 7,KC: KN32: 2015, KN35: 2015,CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,RCM: AS/NZS 60950.1:2003 + Am1, Am2 and Am3,AS/NZS CISPR 32:2015
  • Safety: UL: UL 62368-1,CB: IEC 62368-1: 2014+A11,CE-LVD: EN 62368-1: 2014/A11: 2017,BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,LOA: IEC/EN 60950-1
  • Environment: CE-RoHS: 2011/65/EU+2015/863
  • Audio Type: Mono sound
  • Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
  • Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
  • Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
  • Environment Noise Filtering: Yes
  • Picture Overlay: LOGO picture can be overlaid on video with 128 x 128 24 bit bmp format.
  • Built-in Microphone: Yes
  • Audio: -S: 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KO, interface type: non-equilibrium,-S: 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 O, interface type: non-equilibrium
  • Alarm: -S: 1 input(s), 1 output(s) (max. 24 VDC/24 VAC, 1 A)
  • RS-485: -S: 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
  • People Counting: Counts people entering and exiting separatelySupports real-time uploading and uploading by statistic cycleSends email reports on daily, weekly, monthly or annually basisSupports target filtering by height
  • Material: Front cover: plastic, camera body: metal

Camera
  • Image Sensor: 1/2.7" Progressive Scan CMOS
  • Max. Resolution: 2560 x 1440
  • Min. Illumination: Colour: 0.0176 Lux @ (F2.25, AGC ON),B/W: 0.0035 Lux @ (F2.25, AGC ON), B/W: 0 Lux with IR
  • Shutter Time: 1/25 s to 1/100,000 s
  • Day & Night: IR cut filter

Lens
  • Lens Type: Fixed focal lens, 2 mm
  • Focal Length & FOV: 2 mm, horizontal FOV 104.5°, vertical FOV 70.5°, diagonal FOV 112°
  • Lens Mount: M12
  • Aperture: F2.25

Illuminator
  • Supplement Light Type: IR
  • Supplement Light Range: Up to 6 m
  • IR Wavelength: 850 nm

Video
  • Main Stream: 50 Hz: 25 fps (2560 x 1440, 1920 x 1080, 1280 x 720)60 Hz: 30 fps (2560 x 1440, 1920 x 1080, 1280 x 720)
  • Sub-Stream: 50 Hz: 25 fps (704 x 576, 640 x 480)60 Hz: 30 fps (704 x 480, 640 x 480)
  • Video Compression: Main stream: H.265+/H.265/H.264+/H.264,Sub-stream: H.265/H.264/MJPEG
  • Video Bit Rate: 32 Kbps to 8 Mbps
  • H.264 Type: Baseline Profile, Main Profile, High Profile
  • H.265 Type: Main Profile
  • Scalable Video Coding (SVC): H.264 and H.265 encoding
  • Region of Interest (ROI): 4 fixed region(s) for main stream and sub-stream
  • Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
  • Simultaneous Live View: Up to 20 channels
  • API: Open Network Video Interface (Profile S, Profile G),ISAPI,SDK
  • User/Host: Up to 32 users3 user levels: administrator, operator, and user
  • Security: Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.3, host authentication (MAC address)
  • Client: iVMS-4200,Hik-Connect
  • Web Browser: Plug-in required live view: IE 10, IE 11,Plug-in free live view: Chrome 57.0+, Firefox 52.0+,Local service: Chrome 57.0+, Firefox 52.0+, Safari12+

  • Image Settings: Saturation, brightness, contrast, sharpness, adjustable by client software or web browser
  • Day/Night Switch: Day, Night, Auto, Schedule, Alarm Trigger (-S)
  • Wide Dynamic Range (WDR): 120 dB
  • Image Enhancement: BLC,HLC,3D DNR, defog

Interface
  • Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
  • On-Board Storage: Built-in eMMC storage, up to 8 GB for people counting data

Event
  • Basic Event: Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
  • Linkage: Upload to FTP/NAS/memory card, notify surveillance centre, send email, trigger recording, trigger capture

General
  • Power: 12 VDC ± 20%, 0.58 A, max. 7.0 W,Ø5.5 mm coaxial power plug, reverse polarity protection,PoE: 802.3af, Type 1, Class 3, 36 V to 57 V, 0.24 A to 0.15 A, max. 8.5 W
  • Dimension: 168 mm x 61 mm x 36 mm (6.6" x 2.4" x 1.4")
  • Package Dimension: 235 mm x 120 mm x 125 mm (9.2" x 4.7" x 4.9")
  • Weight: Approx. 340 g (1 lb.)
  • With Package Weight: Approx. 695 g (1.6 lb.)
  • Storage Conditions: -30 °C to 60 °C (-22 °F to 144 °F). Humidity 95% or less (non-condensing)
  • Startup and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Language: 32 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
  • General Function: Heartbeat, anti-flicker, mirror, password protection

Approval
  • EMC: FCC: 47 CFR Part 15, Subpart B,IC: ICES-003: Issue 7,KC: KN32: 2015, KN35: 2015,CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,RCM: AS/NZS 60950.1:2003 + Am1, Am2 and Am3,AS/NZS CISPR 32:2015
  • Safety: UL: UL 62368-1,CB: IEC 62368-1: 2014+A11,CE-LVD: EN 62368-1: 2014/A11: 2017,BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,LOA: IEC/EN 60950-1
  • Environment: CE-RoHS: 2011/65/EU+2015/863

Other
  • Audio Type: Mono sound
  • Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
  • Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
  • Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
  • Environment Noise Filtering: Yes
  • Picture Overlay: LOGO picture can be overlaid on video with 128 x 128 24 bit bmp format.
  • Built-in Microphone: Yes
  • Audio: -S: 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KO, interface type: non-equilibrium,-S: 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 O, interface type: non-equilibrium
  • Alarm: -S: 1 input(s), 1 output(s) (max. 24 VDC/24 VAC, 1 A)
  • RS-485: -S: 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
  • People Counting: Counts people entering and exiting separatelySupports real-time uploading and uploading by statistic cycleSends email reports on daily, weekly, monthly or annually basisSupports target filtering by height
  • Material: Front cover: plastic, camera body: metal
