Hikvision DS-2DE5425IWG-K/4G 4MP PTZ IP Camera 25× Zoom 4G AcuSense CCTV
Specifications
- Image Sensor: 1/2.8" progressive scan CMOS
- Max. Resolution: 2560 × 1440
- Min. Illumination: color: 0.05Lux @ (F1.6,AGC ON)||B/W: 0.01Lux @(F1.6,AGC ON)||0 Lux with IR
- Day & Night: IR cut filter
- Aperture: F1.6
- Supplement Light Type: IR
- Supplement Light Range: IR distance: up to 150 m
- Main Stream: 50 Hz:25 fps(2560 × 1440,1920 × 1080,1280 × 960,1280 × 720)60 Hz:30 fps(2560 × 1440,1920 × 1080,1280 × 960,1280 × 720)
- Sub-Stream: 50 Hz:25 fps(704 × 576,640 × 480,352 × 288)60 Hz:30 fps(704 × 480,640 × 480,352 × 240)
- Third Stream: 50 Hz:25 fps(1920 × 1080,1280 × 960,1280 × 720,704 × 576,640 × 480,352 × 288)60 Hz:30 fps(1920 × 1080,1280 × 960,1280 × 720,704 × 480,640 × 480,352 × 240)
- Video Compression: H.265||H.264||MJPEG
- H.264 Type: Baseline Profile||Main Profile||High Profile
- H.265 Type: Main Profile
- Scalable Video Coding (SVC): yes
- Region of Interest (ROI): fixed region
- Protocols: IPv4/IPv6||HTTP||HTTPS||802.1x||Qos||FTP||SMTP||UPnP||SNMP||DNS||DDNS||NTP||RTSP||RTCP||RTP||TCP/IP||UDP||IGMP||ICMP||DHCP||Bonjour||WebSocket||WebSockets
- API: Open-ended API|| ISAPI||Hikvision SDK||Third-party management platform||Hik-Connect||ISUP||Open Network Video Interface
- User/Host: 32
- Security: Authenticated username and password||MAC address binding||HTTPS encryption||802.1X authenticated access||IP address filter
- Network Storage: NAS (NFS, SMB/ CIFS)
- Client: iVMS-4200
- Web Browser: Chrome 57+?Firefox 52+?Safari 12+||IE10-11
- Image Parameters Switch: yes
- Image Settings: saturation||brightness||contrast||sharpness
- Day/Night Switch: day||night||auto||scheduled-switch
- Wide Dynamic Range (WDR): yes
- SNR: >52dB
- Image Enhancement: BLC
- Privacy Mask: up to 24 masks||mask color configurable
- Ethernet Interface: RJ45, self-adaptive 10M/100M Ethernet port
- Basic Event: Motion detection,video tampering alarm,alarm input and output,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
- Smart Event: Line crossing detection,intrusion detection,region entrance detection,region exiting detection,unattended baggage detection,object removal detection,audio exception detection,Face detection
- Linkage: Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,and PTZ actions (such as preset, patrol scan, pattern scan)
- Power: 12 VDC
- Dimension: Ø208 mm × 344.8 mm
- Weight: Approx. 29.9 kg (65.9 lb.)With Package Weight:Approx. 35.3 kg (77.8 lb.)
- Protection: IP66 Standard; 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
- Shutter Speed: 1 s~1/30,000 s
- Zoom: 25 × optical,16 × digital
- Slow Shutter: yes
- HLC: yes
- 3D DNR: yes
- Focal Length: 4.8 mm~120 mm
- FOV: Horizontal field of view: 55° to 2.4° (wide-tele),Vertical field of view: 33° to 1.4° (wide-tele),Diagonal field of view: 61.5° to 2.8° (wide-tele)
- Focus: semi-auto||manual||auto
- Zoom Speed: approx.3.6s
- Movement Range (Pan): 360°
- Movement Range (Tilt): -15° to 90° (auto flip)
- Pan Speed: pan speed: configurable from 0.1° to 120°/s; preset speed: 120°/s
- Tilt Speed: tilt speed: configurable from 0.1° to 80°/s, preset speed 80°/s
- Proportional Pan: yes
- Presets: 300
- Preset Freezing: yes
- Patrol Scan: 8 patrols, up to 32 presets for each patrol
- Pattern Scan: 4 pattern scans
- Park Action: preset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan
- 3D Positioning: yes
- PTZ Status Display: yes
- Scheduled Task: preset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan||dome reboot||dome adjust||aux output
- Power-off Memory: yes
- Audio Compression: G.711,G.722.1,G.726,MP2L2,MP3,PCM,AAC-LC
- Audio Sampling Rate: MP2L2: 16 kHz, 32 kHz, 48 kHz,AAC-LC: 16 kHz, 32 kHz, 48 kHz,PCM: 8 kHz, 16 kHz, 32 kHz,48kHz,MP3: 8 kHz, 16 kHz, 32 kHz, 48 kHz
- Environment Noise Filtering: yes
- Wireless Range: Up to 20 m (The performance varies based on actual environment)
- Frequency: LTE FDD/LTE TDD/WCDMA/HSPA+/GSM/GPRS/EDGE
- Standard: LTE FDD:Band 1,3,5,7,8,20,28 LTE TDD:Band 38,40,41 WCDMA/HSPA+:Band 1,5,8 GSM/GPRS/EDGE:850/900/1800MH
- Defog: yes
- Regional Focus: yes
- Regional Exposure: yes
- On-board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB,Built-in eMMC storage, up to 256 GB
- Audio: 1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10%, 1 audio output, line level, impedance: 600 O
- Alarm: 2 alarm inputs
- Reset: yes
- Power Output: 12 VDC, max. 1000 mA
- Material: Metal
- Operating Condition: -30? to 65? (-22°F to 149°F)
- Demist: yes
- Power Consumption and Current: Max. 20 W (including max. 7 W for IR and max. 1.6 W for heater);
- Battery Type: Lithium
- Battery Voltage: 10.8 V
- Capacity: 360 WH (90 WH for each battery)
- Operating Temperature: Charging: -20 °C to 45 °C (-4 °F to 113 °F) Discharging: -20 °C to 60 °C (-4 °F to 140 °F)
- Cycle Lifetime: Performance mode: 2 days. Proactive mode: 2.5 days. Standby mode: 80 days *in cloudy/rainy days (25 °C)
- Battery Life: More than 500 cycles
- Battery Weight: Approx. 2.74 kg (6.0 lb.) (0.685 kg (1.5 lb.) for each battery)
