Hikvision DS-2XS6A46G1-IZS/C36S80(2.8-12mm) 4MP Solar-Powered IP Camera CCTV

Hikvision DS-2XS6A46G1-IZS/C36S80(2.8-12mm) 4MP Solar-Powered IP Camera CCTV

Category: IP CCTV
|
Brand: Hikvision
  • IP CCTV
  • 4MP
  • Verifocal
  • 40 years of Trust
  • Free Delivery
  • Free Returns
  • Expert Tech Support
View full details
Hikvision DS-2XS6A46G1-IZS/C36S80(2.8-12mm) 4MP Solar-Powered IP Camera CCTV
Login to View Price

Specifications

  • Image Sensor: 1/1.8" Progressive Scan CMOS
  • Max. Resolution: 2560 x 1440
  • Min. Illumination: Colour: 0.0005 Lux @ (F1.2, AGC ON), B/W: 0 Lux with light
  • Shutter Time: 1 s to 1/100,000 s
  • Lens Type: Auto, Semi-auto, Manual
  • Focal Length & FOV: 2.8 to 12 mm, horizontal FOV 107.4° to 39.8°, vertical FOV 56° to 22.4°, diagonal FOV 130.1° to 45.7°
  • Lens Mount: All In One Lens
  • Iris Type: Auto-iris
  • Aperture: 2.8 to 12 mm: F1.2
  • DORI: 2.8 to 12 mm:Wide: D: 60.0 m, O: 23.8 m, R: 12.0 m, I: 6.0 mTele: D: 149.0 m, O: 59.1 m, R: 29.8 m, I: 14.9 m
  • Supplement Light Type: IR
  • Supplement Light Range: 2.8 to 12 mm: Up to 30 m
  • Smart Supplement Light: Yes
  • Main Stream: Performance mode:50 Hz: 25 fps (2560 x 1440, 1920 x 1080, 1280 x 720)60 Hz: 30 fps (2560 x 1440, 1920 x 1080, 1280 x 720)Proactive mode:50 Hz: 12.5 fps (2560 x 1440, 1920 x 1080, 1280 x 720)60 Hz: 15 fps (2560 x 1440, 1920 x 1080, 1280 x 720)
  • Sub-Stream: Performance mode:50 Hz: 25 fps (640 x 480, 640 x 360)60 Hz: 30 fps (640 x 480, 640 x 360)Proactive mode:50 Hz: 12.5 fps (640 x 480, 640 x 360)60 Hz: 15 fps (640 x 480, 640 x 360)
  • Third Stream: 50 Hz: 1 fps (1280 x 720, 640 x 480)60 Hz: 1 fps (1280 x 720, 640 x 480)
  • Video Compression: Main stream: H.264/H.265Sub-stream: H.264/H.265/MJPEGThird Stream: H.265/H.264*Performance mode: main stream supports H.264+, H.265+
  • Video Bit Rate: 32 Kbps to 8 Mbps
  • H.264 Type: Baseline Profile, Main Profile, High Profile
  • H.265 Type: Main Profile
  • Bit Rate Control: CBR/VBR
  • Scalable Video Coding (SVC): H.264 and H.265 encoding
  • Region of Interest (ROI): 4 fixed regions for main stream
  • Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
  • Simultaneous Live View: Up to 6 channels
  • API: Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP, OTAP
  • User/Host: Up to 32 users3 user levels: administrator, operator, and user
  • Security: Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, TLS 1.2, TLS 1.3
  • Network Storage: NAS (NFS, SMB/CIFS), auto network replenishment (ANR)Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
  • Client: Hik-Connect (proactive mode also supports), Hik-central Professional
  • Web Browser: Plug-in required live view: IE 10+Plug-in free live view: Chrome 57.0+, Firefox 52.0+Local service: Chrome 57.0+, Firefox 52.0+
  • Image Parameters Switch: Yes
  • Image Settings: Saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
  • Day/Night Switch: Day, Night, Auto, Schedule
  • Wide Dynamic Range (WDR): 120 dB
  • SNR: ≥ 52 dB
  • Image Enhancement: BLC, HLC, 3D DNR, Defog
  • Privacy Mask: 4 programmable polygon privacy masks
  • Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
  • On-Board Storage: Built-in memory card slot, support microSD card, up to 256 GB,Built-in 256 GB eMMC storage (256 GB device model supports),Built-in 512 GB SSD storage (512 GB device model supports),Built-in 1 TB SSD storage (1 TB device model supports)
  • Reset Key: Yes
  • Basic Event: Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD error)
  • Smart Event: Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, scene change detection, face detection
  • Linkage: Upload to FTP/NAS/memory card, notify surveillance centre, send email, trigger recording, trigger capture, trigger alarm output, audible warning
  • Power: 12 VDC ± 20%, 4-pin M8 waterproof connector1 TB/512 GB device model:1. Standby power consumption: 45 mW2. The average power consumption of 24 hours (4G transmission is excluded): 4.5 W3. The max. power consumption: 20 W (6 W if without 12 V load)Other device model:1. Standby power consumption: 45 mW2. The average power consumption of 24 hours (4G transmission is excluded): 3 W3. The max. power consumption: 18 W (6 W if without 12 V load)
  • Dimension: 816.2 mm x 735.9 mm x 760 mm (32.1" x 28.9" x 29.9") (Max. size of the camera after it is completely assembled)
  • Package Dimension: 862 mm x 352 mm x 762 mm (33.9" x 13.9" x 30.0")
  • Weight: Approx. 26.450 kg (58.3 lb.)
  • With Package Weight: Approx. 32.715 kg (72.1 lb.)
  • Storage Conditions: -20 °C to 60 °C (-4 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Startup and Operating Conditions: -20 °C to 60 °C (-4 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Language: 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
  • General Function: Anti-banding, heartbeat, mirror, flash log, password reset via email, pixel counter
  • EMC: CE-EMC/UKCA (EN 55032:2015+A11:2020+A1:2020,EN 50130-4:2011+A1:2014);RCM (AS/NZS CISPR 32: 2015);IC (ICES-003: Issue 7)
  • Safety: CB (IEC 62368-1:2014+A11)CE-LVD/UKCA (EN 62368-1:2014/A11:2017)LOA (IEC/EN 60950-1)
  • Environment: CE-RoHS (2011/65/EU);WEEE (2012/19/EU);Reach (Regulation (EC) No 1907/2006)
  • Protection: Camera: IP66 (IEC 60529-2013)Wind resistance 12 level, up to 40 m/s wind speed resistance
  • Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
  • Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
  • Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
  • Environment Noise Filtering: Yes
  • SIM Card Type: MicroSIM
  • Frequency: DS-2XS6A46G1-IZS/C36S80:LTE-TDD: Band38/40/41LTE-FDD: Band1/3/5/7/8/20/28WCDMA: Band1/5/8GSM: 850/900/1800 MHzDS-2XS6A46G1-IZS/C36S80(US):LTE-FDD: Band2/4/5/12/13/66/71WCDMA: Band2/4/5DS-2XS6A46G1-IZS/C36S80(LA):LTE-TDD: Band38/40LTE-FDD: Band1/2/3/4/5/7/8/12/17/28/66WCDMA: Band1/2/3/4/5/8GSM: 850/900/1800/1900 MHzDS-2XS6A46G1-IZS/C36S80(JP):LTE-TDD: Band41LTE-FDD: Band1/3/8/11/18/19/21/26/28WCDMA: Band1/6/8/19
  • Standard: DS-2XS6A46G1-IZS/C36S80: LTE-TDD/LTE-FDD/WCDMA/GSMDS-2XS6A46G1-IZS/C36S80 (US): LTE-FDD/WCDMADS-2XS6A46G1-IZS/C36S80 (LA): LTE-TDD/LTE-FDD/WCDMA/GSMDS-2XS6A46G1-IZS/C36S80 (JP): LTE-TDD/LTE-FDD/WCDMA
  • Audio: 1 input (line in), max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,1 output (line out), max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
  • Alarm: 1 input, 1 output (max. 12 VDC, 1 A)
  • Power Output: 12 VDC, max. 1000 mA
  • Material: Front cover: metal, body: metal, bracket: metal
  • Battery Type: Lithium
  • Capacity: 360 Wh (90 Wh for each battery)
  • Battery Voltage: 10.8 V
  • Max. Output Voltage: 12.6 V
  • Operating Temperature: Charging: -20 °C to 45 °C (-4 °F to 113 °F)Discharging: -20 °C to 60 °C (-4 °F to 140 °F)
  • Battery Life: More than 500 cycles
  • Cycle Lifetime: Proactive mode: 8 days, Standby mode: 80 days*in cloudy/rainy days (25 °C)
  • Battery Weight: Approx. 2.74 kg (6.0 lb.) (0.685 kg (1.5 lb.) for each battery)
  • RF: CE-RED/UKCA (EN 301908-1,EN 301908-2,EN 301908-13, EN 301511,EN 301489-1,EN 301489-52,EN 62133);ICASA: same as CE-RED;IC ID (RSS-132 Issue 3, RSS-133 Issue 6, RSS-139 Issue 3, RSS-130 Issue 2, RSS-102 Issue 5);MIC (Article 49-6-4 and 49-6-5 the relevant articles and MIC Notice No. 1299 of the Ordinance Regulating Radio Equipment)

Camera
  • Image Sensor: 1/1.8" Progressive Scan CMOS
  • Max. Resolution: 2560 x 1440
  • Min. Illumination: Colour: 0.0005 Lux @ (F1.2, AGC ON), B/W: 0 Lux with light
  • Shutter Time: 1 s to 1/100,000 s

Lens
  • Lens Type: Auto, Semi-auto, Manual
  • Focal Length & FOV: 2.8 to 12 mm, horizontal FOV 107.4° to 39.8°, vertical FOV 56° to 22.4°, diagonal FOV 130.1° to 45.7°
  • Lens Mount: All In One Lens
  • Iris Type: Auto-iris
  • Aperture: 2.8 to 12 mm: F1.2

DORI
  • DORI: 2.8 to 12 mm:Wide: D: 60.0 m, O: 23.8 m, R: 12.0 m, I: 6.0 mTele: D: 149.0 m, O: 59.1 m, R: 29.8 m, I: 14.9 m

Illuminator
  • Supplement Light Type: IR
  • Supplement Light Range: 2.8 to 12 mm: Up to 30 m
  • Smart Supplement Light: Yes

Video
  • Main Stream: Performance mode:50 Hz: 25 fps (2560 x 1440, 1920 x 1080, 1280 x 720)60 Hz: 30 fps (2560 x 1440, 1920 x 1080, 1280 x 720)Proactive mode:50 Hz: 12.5 fps (2560 x 1440, 1920 x 1080, 1280 x 720)60 Hz: 15 fps (2560 x 1440, 1920 x 1080, 1280 x 720)
  • Sub-Stream: Performance mode:50 Hz: 25 fps (640 x 480, 640 x 360)60 Hz: 30 fps (640 x 480, 640 x 360)Proactive mode:50 Hz: 12.5 fps (640 x 480, 640 x 360)60 Hz: 15 fps (640 x 480, 640 x 360)
  • Third Stream: 50 Hz: 1 fps (1280 x 720, 640 x 480)60 Hz: 1 fps (1280 x 720, 640 x 480)
  • Video Compression: Main stream: H.264/H.265Sub-stream: H.264/H.265/MJPEGThird Stream: H.265/H.264*Performance mode: main stream supports H.264+, H.265+
  • Video Bit Rate: 32 Kbps to 8 Mbps
  • H.264 Type: Baseline Profile, Main Profile, High Profile
  • H.265 Type: Main Profile
  • Bit Rate Control: CBR/VBR
  • Scalable Video Coding (SVC): H.264 and H.265 encoding
  • Region of Interest (ROI): 4 fixed regions for main stream
  • Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
  • Simultaneous Live View: Up to 6 channels
  • API: Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP, OTAP
  • User/Host: Up to 32 users3 user levels: administrator, operator, and user
  • Security: Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, TLS 1.2, TLS 1.3
  • Network Storage: NAS (NFS, SMB/CIFS), auto network replenishment (ANR)Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
  • Client: Hik-Connect (proactive mode also supports), Hik-central Professional
  • Web Browser: Plug-in required live view: IE 10+Plug-in free live view: Chrome 57.0+, Firefox 52.0+Local service: Chrome 57.0+, Firefox 52.0+

  • Image Parameters Switch: Yes
  • Image Settings: Saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
  • Day/Night Switch: Day, Night, Auto, Schedule
  • Wide Dynamic Range (WDR): 120 dB
  • SNR: ≥ 52 dB
  • Image Enhancement: BLC, HLC, 3D DNR, Defog
  • Privacy Mask: 4 programmable polygon privacy masks

Interface
  • Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
  • On-Board Storage: Built-in memory card slot, support microSD card, up to 256 GB,Built-in 256 GB eMMC storage (256 GB device model supports),Built-in 512 GB SSD storage (512 GB device model supports),Built-in 1 TB SSD storage (1 TB device model supports)
  • Reset Key: Yes

Event
  • Basic Event: Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD error)
  • Smart Event: Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, scene change detection, face detection
  • Linkage: Upload to FTP/NAS/memory card, notify surveillance centre, send email, trigger recording, trigger capture, trigger alarm output, audible warning

General
  • Power: 12 VDC ± 20%, 4-pin M8 waterproof connector1 TB/512 GB device model:1. Standby power consumption: 45 mW2. The average power consumption of 24 hours (4G transmission is excluded): 4.5 W3. The max. power consumption: 20 W (6 W if without 12 V load)Other device model:1. Standby power consumption: 45 mW2. The average power consumption of 24 hours (4G transmission is excluded): 3 W3. The max. power consumption: 18 W (6 W if without 12 V load)
  • Dimension: 816.2 mm x 735.9 mm x 760 mm (32.1" x 28.9" x 29.9") (Max. size of the camera after it is completely assembled)
  • Package Dimension: 862 mm x 352 mm x 762 mm (33.9" x 13.9" x 30.0")
  • Weight: Approx. 26.450 kg (58.3 lb.)
  • With Package Weight: Approx. 32.715 kg (72.1 lb.)
  • Storage Conditions: -20 °C to 60 °C (-4 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Startup and Operating Conditions: -20 °C to 60 °C (-4 °F to 140 °F). Humidity 95% or less (non-condensing)
  • Language: 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
  • General Function: Anti-banding, heartbeat, mirror, flash log, password reset via email, pixel counter

Approval
  • EMC: CE-EMC/UKCA (EN 55032:2015+A11:2020+A1:2020,EN 50130-4:2011+A1:2014);RCM (AS/NZS CISPR 32: 2015);IC (ICES-003: Issue 7)
  • Safety: CB (IEC 62368-1:2014+A11)CE-LVD/UKCA (EN 62368-1:2014/A11:2017)LOA (IEC/EN 60950-1)
  • Environment: CE-RoHS (2011/65/EU);WEEE (2012/19/EU);Reach (Regulation (EC) No 1907/2006)
  • Protection: Camera: IP66 (IEC 60529-2013)Wind resistance 12 level, up to 40 m/s wind speed resistance

Other
  • Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
  • Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
  • Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
  • Environment Noise Filtering: Yes
  • SIM Card Type: MicroSIM
  • Frequency: DS-2XS6A46G1-IZS/C36S80:LTE-TDD: Band38/40/41LTE-FDD: Band1/3/5/7/8/20/28WCDMA: Band1/5/8GSM: 850/900/1800 MHzDS-2XS6A46G1-IZS/C36S80(US):LTE-FDD: Band2/4/5/12/13/66/71WCDMA: Band2/4/5DS-2XS6A46G1-IZS/C36S80(LA):LTE-TDD: Band38/40LTE-FDD: Band1/2/3/4/5/7/8/12/17/28/66WCDMA: Band1/2/3/4/5/8GSM: 850/900/1800/1900 MHzDS-2XS6A46G1-IZS/C36S80(JP):LTE-TDD: Band41LTE-FDD: Band1/3/8/11/18/19/21/26/28WCDMA: Band1/6/8/19
  • Standard: DS-2XS6A46G1-IZS/C36S80: LTE-TDD/LTE-FDD/WCDMA/GSMDS-2XS6A46G1-IZS/C36S80 (US): LTE-FDD/WCDMADS-2XS6A46G1-IZS/C36S80 (LA): LTE-TDD/LTE-FDD/WCDMA/GSMDS-2XS6A46G1-IZS/C36S80 (JP): LTE-TDD/LTE-FDD/WCDMA
  • Audio: 1 input (line in), max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,1 output (line out), max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
  • Alarm: 1 input, 1 output (max. 12 VDC, 1 A)
  • Power Output: 12 VDC, max. 1000 mA
  • Material: Front cover: metal, body: metal, bracket: metal
  • Battery Type: Lithium
  • Capacity: 360 Wh (90 Wh for each battery)
  • Battery Voltage: 10.8 V
  • Max. Output Voltage: 12.6 V
  • Operating Temperature: Charging: -20 °C to 45 °C (-4 °F to 113 °F)Discharging: -20 °C to 60 °C (-4 °F to 140 °F)
  • Battery Life: More than 500 cycles
  • Cycle Lifetime: Proactive mode: 8 days, Standby mode: 80 days*in cloudy/rainy days (25 °C)
  • Battery Weight: Approx. 2.74 kg (6.0 lb.) (0.685 kg (1.5 lb.) for each battery)
  • RF: CE-RED/UKCA (EN 301908-1,EN 301908-2,EN 301908-13, EN 301511,EN 301489-1,EN 301489-52,EN 62133);ICASA: same as CE-RED;IC ID (RSS-132 Issue 3, RSS-133 Issue 6, RSS-139 Issue 3, RSS-130 Issue 2, RSS-102 Issue 5);MIC (Article 49-6-4 and 49-6-5 the relevant articles and MIC Notice No. 1299 of the Ordinance Regulating Radio Equipment)
