Hikvision DS-K1T342MFWX-E1 | Facial Recognition Terminal
Hikvision DS-K1T342MFWX-E1 | Facial Recognition Terminal
- Access Control
- Face Recognition Terminals
- Value Series
Face Recognition Terminal, 4.3-inch LCD touch screen,2 Mega pixel wide-angle lens,Built-in M1 card reading module;
Max.1,500 faces capacity ，Max.3,000 cards;Max.3,000 fingerprints capacity
Face recognition in dark environment
Two-way audio with client software, indoor station, and master station
Supports TCP/IP, WiFi,DC 12V/1A, Standard PoE
Supports ISUP5.0, ISAPI
Supports 6 attendance status, including check in, check out, break in, break out, overtime in, overtime out
multiple languages: English, Spanish South America , Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese Brazil
Configuration via the web client
Face Recognition Accuracy Rate > 99%
Face Recognition Duration 1:N ≤0.2s
Face Recognition Distance: 0.3m ~ 1.5m
IP65
Power adapter included in the package European Standard
-
40 years of Trust
-
Free Delivery
-
Free Returns
-
Expert Tech Support
Specifications
- CPU: 900 MHz
- Memory: DDR3:512 M
- Flash: 4 GB
- Operation system: Linux
- Dimensions: 4.3-inch
- Resolution: 272 × 480
- Type: LCD
- Operation method: Capacitive touch screen
- Lumens: 250cd
- Pixel: 2 MP
- Lens: × 2
- Focal length: 4 mm
- WDR: Support
- Aperture: F2.0
- HOV: HFOV：75.5°； VFOV：41.5°； DFOV：87°
- Video standard: PAL (Default) and NTSC
- Audio input: Built-in omnidirectional microphone
- Audio output: Built-in loudspeaker
- Volume adjustment: Adjust via device or client
- Power output: 8 Ω, 1.5 W
- Audio compression standard: G.711U
- Audio compression bitrate: 64 Kbps
- Tone quality: Noise suppression and echo cancellation
- Wired network: 10 M/100 M self-adaptive
- Wi-Fi: Support
- Communication protocol: ISAPI, ISUP5.0
- PoE: IEEE802.3at, standard PoE
- Network interface: 1
- RS-485: 1
- Wiegand: 1
- Lock output: 1
- Exit button: 1
- Door contact input: 1
- TAMPER: 1
- USB: 1
- User capacity: 1500
- Card capacity: 3,000
- Face capacity: 1,500
- Fingerprint capacity: 3,000
- Event capacity: 150,000
- Card type: M1 card
- Card reading frequency: 13.56 MHz
- Card reading distance: 0 to 5 cm (Normal Card); 0 to 3 cm (Card with Different Shapes)
- Card reading duration: ＜ 1 s
- Face recognition duration: ＜ 0.2 s
- Face recognition accuracy rate: ＞99%
- Face recognition distance: 0.3 to 1.5 m
- Fingerprint recognition duration: ＜1 s
- button: Touch Screen
- Supplement light: IR light
- Power supply: Power input: Power interface (power adapter included, 12 VDC/1 A) or PoE (37 to 57 VDC/0.6 A) Power output: Power supply for door lock, 12 VDC/1 A (only when the device is powered by PoE supporting powering supply for door lock)
- Working temperature: -30 °C to 60 °C (-22 °F to 140 °F)
- Working humidity: 0 to 90% (No condensing)
- Dimensions: 91.3 mm × 181.3 mm × 24.5 mm (3.59" × 7.14" × 0.96")
- Installation: Wall Mounting
- Protective level: IP65
- Language: English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil), Korean
- Weight: Gross weight: 0.93 kg (2.05 lbs) Net weight: 0.36 kg (0.79 lbs)
- Platform: Hik-ProConnect and HikCentral Professional
- QR code recognition: Support QR code 2.0
- Multiple faces detection: Not support
- Face anti-spoofing: Support
- Live view: Support
- Two-way audio: Support
- Advertisement: Not support
- Audio prompt: Support
- M1 card encryption: Support
- Anti-passback: Not support
- First person in: Support
- Multi-factor authentication: Support
- Time synchronization: Support
