Access Control Terminal, 2 Mega pixels camera, Built-in M1 card, Felica card,DESfire card reading module and Bluetooth module;
AP mode
access control, video intercoms, and video all in one
IP65, IK09，increased stability with zinc alloy materials
Storage with 100,000 cards, 10,000 fingerprints and 300,000 events;
support mobile APP hikconnect
Supports two-way audio intercom, remote live view, video recording through NVR, capacitive Fingerprint Module;
Uplink Communication: TCP/IP, WIFI; Downlink Communication: RS-485;
Supports SD card
-
40 years of Trust
-
Free Delivery
-
Free Returns
-
Expert Tech Support
Hikvision DS-K1T502DBFWX-C | Access Control Terminal
Specifications
- Operating system: Linux
- ROM: 4 GB
- RAM: 256 MB
- CPU: 960 MHz
- Lens: 1
- Video compression standard: H.264 and H.265
- Resolution: 2 MP
- FOV: HFOV = 110°; VFOV = 81°; DFOV = 122°
- Video standard: PAL (Default) and NTSC
- Aperture: F 2.0
- Audio input: Build-in omnidirectional microphone
- Audio output: Build-in loudspeaker
- Volume adjustment: Adjust via web or client
- Communication protocol: IPV4: SADP, SIP 2.0, SIP, RTSP, ISAPI (80\443 Interface), ISAPI, ISUP 5.0; IPV6: SADP, SIP, RTSP, ISAPI (80\443 Interface), ISAPI
- Wired network: 10 M/100 M self-adaptive
- Wi-Fi: Support
- Bluetooth: Support
- Network interface: 1
- Lock control: 1
- Exit button: 1
- Door contact input: 1
- Alarm input: 1
- Alarm output: 1
- TAMPER: 1
- RS-485: 1
- Wiegand: 1 (output)
- SD Card Slot: 1
- Fingerprint capacity: 10,000
- Card capacity: 100,000
- Event capacity: 300,000
- Fingerprint module: Capacitive fingerprint recognition
- Card type: M1 card;DESfire card
- Card reading distance: 0 ~ 3 cm
- Card reading duration: < 1 s
- Built-in access controller: Support
- Supplement light: White light and IR light
- Power supply: 1 A (12 VDC to 24 VDC)
- Power consumption: ≤12 W
- Working temperature: -40 °C to +70 °C (-40 °F to +158 °F)
- Protective level: IK09, IP65
- Language: Arabic, English, French, Indonesian, Italian, Portuguese (Brazil), Russian, Spanish (Europe), Thai, Ukrainian, Vietnamese, German, Polish, Hungarian, Czech, Romanian, Bulgarian, Croatian, Serbian, Greek, Slovak, Portuguese, Dutch, and Turkish
- Live view: Support
- Two-way audio: Support
- Video intercom: Support
- Multi-factor authentication: Support
- Hik-Connect: Support
