Communicates with the access control terminal via RS-485 to execute the commands from the terminal including open door, close door, normally open and normally closed.
Collects the door magnetic signal and the exit button signal and send them to the access control terminal.
Supports exit button linkage.
-
40 years of Trust
-
Free Delivery
-
Free Returns
-
Expert Tech Support
Hikvision DS-K2M062 | Accessories
Specifications
- Lock control: 1
- Exit button: 1
- Door contact input: 1
- RS-485: 1
- Indicator: 1 for power supply
- Power supply: 12 VDC
- Power consumption: 3 W
- Working temperature: -30° C to 60° C (-22° F to 140° F)
- Working humidity: 0% to 90%
- Dimensions: 53.95 mm × 43.5 mm × 15.5 mm
