• DS-K7R83X

Hikvision DS-K7R83X | Turnstile

Hikvision DS-K7R83X | Turnstile

Category: Access Control
|
Brand: Hikvision
  • Access Control
  • Peripheral Products
  • Remote Controller

7-inch IPS touch screen with 1024 × 600 resolution.
Supported IEEE802.3af, standard PoE.
12 VDC/1 A
Cost-effective for traditional remote keyfob.

  • 40 years of Trust
  • Free Delivery
  • Free Returns
  • Expert Tech Support
View full details
Hikvision DS-K7R83X | Turnstile
Login to View Price

Specifications

  • Operating system: Embedded Linux system
  • Screen size: 7-inch
  • Operation method: Capacitive touch screen
  • Type: Colorful IPS LCD
  • Resolution: 1024 × 600
  • Communication protocol: TCP/IP
  • Wired network: 10/100 Mbps self-adaptive
  • Wi-Fi: Wi-Fi 802.11 b/g/n
  • Network interface: x 1 RJ-45 10/100 Mbps self-adaptive
  • Button: Physical button (self-define)
  • Configuration via Web browser: Supported
  • Video intercom: Not supported
  • Power: IEEE802.3af, standard PoE 12 VDC/1 A
  • Power consumption: ≤ 7 W
  • Working temperature: -10 °C to 55 °C (14 °F to 131 °F)
  • Working humidity: 10% to 90%
  • Dimensions: Without package 180 mm × 140 mm × 22.4 mm (7.09" × 5.51" × 0.88") With package (1 for 1) 251 mm x 211 mm x 141 mm (9.88" × 8.31" × 5.55") With package (1 for 12) 522 mm x 442 mm x 453 mm (20.55" × 17.40" × 17.83")
  • Installation: Surface mounting and Desktop placement
  • Weight: Without package: 355 g With package: 1050 g
  • Approval: CE/CE-LVD/CB/RoHS/REACH/WEEE
  • Power supply method: 12 VDC/1 A
  • Language: English, European Spanish, Thai, Japanese, Arabic
  • Module selection: NO

System
  • Operating system: Embedded Linux system

Display
  • Screen size: 7-inch
  • Operation method: Capacitive touch screen
  • Type: Colorful IPS LCD
  • Resolution: 1024 × 600

Network
  • Communication protocol: TCP/IP
  • Wired network: 10/100 Mbps self-adaptive
  • Wi-Fi: Wi-Fi 802.11 b/g/n

Interface
  • Network interface: x 1 RJ-45 10/100 Mbps self-adaptive

Hardware
  • Button: Physical button (self-define)

Function
  • Configuration via Web browser: Supported
  • Video intercom: Not supported

General
  • Power: IEEE802.3af, standard PoE 12 VDC/1 A
  • Power consumption: ≤ 7 W
  • Working temperature: -10 °C to 55 °C (14 °F to 131 °F)
  • Working humidity: 10% to 90%
  • Dimensions: Without package 180 mm × 140 mm × 22.4 mm (7.09" × 5.51" × 0.88") With package (1 for 1) 251 mm x 211 mm x 141 mm (9.88" × 8.31" × 5.55") With package (1 for 12) 522 mm x 442 mm x 453 mm (20.55" × 17.40" × 17.83")
  • Installation: Surface mounting and Desktop placement
  • Weight: Without package: 355 g With package: 1050 g
  • Approval: CE/CE-LVD/CB/RoHS/REACH/WEEE
  • Power supply method: 12 VDC/1 A
  • Language: English, European Spanish, Thai, Japanese, Arabic

Configuration
  • Module selection: NO
