• DS-KAW150-4N

Hikvision DS-KAW150-4N | Two Wire | Power Supply/ Distributor

Hikvision DS-KAW150-4N | Two Wire | Power Supply/ Distributor

Category: Intercom
|
Brand: Hikvision
  • Intercom
  • 2-wire Series
  • 2 Wire HD

Power supply for DS-KAD7060EY& DS-KAD7060EY-S, Output: 48 VDC, 150W, Din rail mounting,

  • 40 years of Trust
  • Free Delivery
  • Free Returns
  • Expert Tech Support
View full details
Hikvision DS-KAW150-4N | Two Wire | Power Supply/ Distributor
Login to View Price

Specifications

  • Working temperature: Operating: -10 °C to +70 °C (14 °F to 158 °F) Storage: -25 °C to +85 °C (-13 °F to 185 °F)
  • Working humidity: < 95% (no condensation)
  • Input voltage: 100 VAC to 240 VAC
  • Output voltage: 48 VDC
  • Output current: 3.2 A
  • Output power: 150 W
  • Noise and ripple: < 150 mVpp @ 25 °C
  • Voltage adjustment range: 23 VDC to 25 VDC
  • Cooling system: Convection
  • Dimension (L x W x D): 105mm × 90mm × 54.5mm
  • Weight: 0.54 kg

General
  • Working temperature: Operating: -10 °C to +70 °C (14 °F to 158 °F) Storage: -25 °C to +85 °C (-13 °F to 185 °F)
  • Working humidity: < 95% (no condensation)
  • Input voltage: 100 VAC to 240 VAC
  • Output voltage: 48 VDC
  • Output current: 3.2 A
  • Output power: 150 W
  • Noise and ripple: < 150 mVpp @ 25 °C
  • Voltage adjustment range: 23 VDC to 25 VDC
  • Cooling system: Convection
  • Dimension (L x W x D): 105mm × 90mm × 54.5mm
  • Weight: 0.54 kg
