Hikvision DS-KD8003Y-IME2 | Two Wire | Outdoor Bell

Hikvision DS-KD8003Y-IME2 | Two Wire | Outdoor Bell

Hikvision DS-KD8003Y-IME2 | Two Wire | Outdoor Bell

Category: Intercom
|
Brand: Hikvision
  • Intercom
  • Two Wire
  • Outdoor Bell

Two-wire version: CMOS 2MP HD Colorful Camera, Fish eye Horizontal: 146°, Vertical:82° , 1 Call Button, 2-ch Indoor station access
IR Supplement , 10M/100M Self-adaptive Ethernet, module connection with RS-485 , 4-ch alarm input
IP65, Two -wire interface,98mmx99.8mmx43.9mm
Mouting accessories and other modules are same as IP version of modular door station.

  • 40 years of Trust
  • Free Delivery
  • Free Returns
  • Expert Tech Support
View full details
Hikvision DS-KD8003Y-IME2 | Two Wire | Outdoor Bell

Specifications

  • Weight: /
  • Language: English, French, Portuguese (Brazil), Spanish, Russian, German, Italian, Polish, Arabic, Turkish, Vietnamese, Hungarian, Dutch, Romanian, Czech, Bulgarian, Ukrainian, Croatian, Serbian, Portuguese, Slovak
  • Size: /
  • Operation method: Physical button
  • Type: /
  • Supplement light: IR supplement
  • FOV: Horizontal 180°, vertical 96°
  • Pixel: Main stream: 1920 x 1080, (720p configurable)Í–; sub stream: 720 x 480
  • Audio quality: Noise suppression and echo cancellation
  • Sub door station capacity: 16
  • Communication protocol: TCP/IP, RTSP
  • Wired network: Two-wire transmission
  • Wi-Fi: /
  • Bluetooth: /
  • Network interface: 0
  • Exit button: 2
  • Lock control: 2
  • Door contact input: 2
  • Power interface: 1
  • Button: 1
  • Installation: Wall mounting
  • Indicator: 0
  • Protective level: IP65
  • Power supply method: 24 VDC two-wire power supply (< 16 W) or 12 VDC independent power supply (< 20 W)
  • Working temperature: -40 °C to 60 °C (-40 °F to 140 °F)
  • Working humidity: 10% to 95%
  • Dimensions: 98 mm x 99.8 mm x 43.9 mm (3.86" x 3.93\" x 1.73\")
  • Battery: /
  • Application environment: Outdoor
  • Power consumption: 4 W

General

  • Weight: /
  • Language: English, French, Portuguese (Brazil), Spanish, Russian, German, Italian, Polish, Arabic, Turkish, Vietnamese, Hungarian, Dutch, Romanian, Czech, Bulgarian, Ukrainian, Croatian, Serbian, Portuguese, Slovak

Other

  • Size: /
  • Operation method: Physical button
  • Type: /
  • Supplement light: IR supplement
  • FOV: Horizontal 180°, vertical 96°
  • Pixel: Main stream: 1920 x 1080, (720p configurable)Í–; sub stream: 720 x 480
  • Audio quality: Noise suppression and echo cancellation
  • Sub door station capacity: 16
  • Communication protocol: TCP/IP, RTSP
  • Wired network: Two-wire transmission
  • Wi-Fi: /
  • Bluetooth: /
  • Network interface: 0
  • Exit button: 2
  • Lock control: 2
  • Door contact input: 2
  • Power interface: 1
  • Button: 1
  • Installation: Wall mounting
  • Indicator: 0
  • Protective level: IP65
  • Power supply method: 24 VDC two-wire power supply (< 16 W) or 12 VDC independent power supply (< 20 W)
  • Working temperature: -40 °C to 60 °C (-40 °F to 140 °F)
  • Working humidity: 10% to 95%
  • Dimensions: 98 mm x 99.8 mm x 43.9 mm (3.86" x 3.93\" x 1.73\")
  • Battery: /
  • Application environment: Outdoor
  • Power consumption: 4 W
