Hikvision DS-KH7300EY-WTE2 | Two Wire | Indoor Monitor

Hikvision DS-KH7300EY-WTE2 | Two Wire | Indoor Monitor

Hikvision DS-KH7300EY-WTE2 | Two Wire | Indoor Monitor

Category: Intercom
|
Brand: Hikvision
  • Intercom
  • Two Wire
  • Indoor Monitor

Two-wire HD version: 7“ Touch-Screen Indoor Station,
7-inch Colorful TFT LCD, display resolution: 1024 * 600;
Wi-Fi 802.11b/g/n;
6 decimal DIP switch;
Two -wire interface.
TF card, max 128G; 4 indicators;
1 floor call
The model with is not compatible with Y version，they can not be used together.

  • 40 years of Trust
  • Free Delivery
  • Free Returns
  • Expert Tech Support
View full details
Hikvision DS-KH7300EY-WTE2 | Two Wire | Indoor Monitor
Login to View Price

Specifications

  • Language: English, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Spanish, Romanian, Estonian, Croatian, Slovenian, Serbian, Ukrainian, Portuguese
  • Operating system: Embedded Linux operation system
  • ROM: 32 MB
  • RAM: 128 MB
  • CPU: Embedded processor
  • Screen size: 7-inch
  • Operation method: Capacitive touch screen
  • Type: Colourful TFT screen
  • Resolution: /
  • FOV: /
  • WDR: /
  • Focal length: /
  • Audio compression standard: G.711 U G.711 A
  • Audio input: 1 Built-in omnidirectional microphone
  • Audio output: 1 Buit-in loudspeaker
  • Audio compression bitrate: 64 Kps
  • Audio quality: Noise suppression and echo cancellation
  • Volume adjustment: Adjustable
  • Event capacity: 200 captured pictures (with TF card)
  • Linked indoor extensions capacity: 3
  • Communication protocol: TCP/IP, RTSP
  • Wi-Fi standard: 2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n
  • 3G/4G standard: /
  • Zigbee: /
  • Alarm input: 1
  • TAMPER: /
  • RS-485: /
  • USB: /
  • TF card: Max to 128 G, SD 2.0 or lower version
  • Alarm output: /
  • DIP switch: 5 decimal DIP switch and 4 binary DIP switch
  • Power supply input: 48V:powered by DS-KAD7060EY or DS-KAD7061EY
  • Two-wire IP interface: 2, 1 for input 1 for output
  • Button: 3 Touch buttons (Answer, Unlock, Hang up) +1 Physical button (Reset）
  • Installation: Surface mounting
  • Indicator: 4（Wifi、Power、Mute、In use）
  • Protective level: /
  • Working temperature: -10 °C to 50 °C (14 °F to 122 °F)
  • Working humidity: 10% to 90% (no-condensing)
  • Dimensions: 190.2 mm x 138.2 mm x 20 mm (7.5" x 5.4" x 0.8")
  • Battery: /
  • Power supply: 48V:Powered by DS-KAD7060EY or DS-KAD7061EY
  • Application environment: Indoor
  • Power consumption: = 5W (stand by = 1.2 W)

General
  • Language: English, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Spanish, Romanian, Estonian, Croatian, Slovenian, Serbian, Ukrainian, Portuguese

Other
  • Operating system: Embedded Linux operation system
  • ROM: 32 MB
  • RAM: 128 MB
  • CPU: Embedded processor
  • Screen size: 7-inch
  • Operation method: Capacitive touch screen
  • Type: Colourful TFT screen
  • Resolution: /
  • FOV: /
  • WDR: /
  • Focal length: /
  • Audio compression standard: G.711 U G.711 A
  • Audio input: 1 Built-in omnidirectional microphone
  • Audio output: 1 Buit-in loudspeaker
  • Audio compression bitrate: 64 Kps
  • Audio quality: Noise suppression and echo cancellation
  • Volume adjustment: Adjustable
  • Event capacity: 200 captured pictures (with TF card)
  • Linked indoor extensions capacity: 3
  • Communication protocol: TCP/IP, RTSP
  • Wi-Fi standard: 2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n
  • 3G/4G standard: /
  • Zigbee: /
  • Alarm input: 1
  • TAMPER: /
  • RS-485: /
  • USB: /
  • TF card: Max to 128 G, SD 2.0 or lower version
  • Alarm output: /
  • DIP switch: 5 decimal DIP switch and 4 binary DIP switch
  • Power supply input: 48V:powered by DS-KAD7060EY or DS-KAD7061EY
  • Two-wire IP interface: 2, 1 for input 1 for output
  • Button: 3 Touch buttons (Answer, Unlock, Hang up) +1 Physical button (Reset）
  • Installation: Surface mounting
  • Indicator: 4（Wifi、Power、Mute、In use）
  • Protective level: /
  • Working temperature: -10 °C to 50 °C (14 °F to 122 °F)
  • Working humidity: 10% to 90% (no-condensing)
  • Dimensions: 190.2 mm x 138.2 mm x 20 mm (7.5" x 5.4" x 0.8")
  • Battery: /
  • Power supply: 48V:Powered by DS-KAD7060EY or DS-KAD7061EY
  • Application environment: Indoor
  • Power consumption: = 5W (stand by = 1.2 W)
