Hikvision DS-KP6000-HE1 | SIP Phone

Hikvision DS-KP6000-HE1 | SIP Phone

Category: Intercom
|
Brand: Hikvision
  • Intercom
  • SIP Phone
  • Value Series

128 x 48 black and white dot matrix screen with backlight; 4 SIP Lines；33 physical keys;
2 10/100Mbps Ethernet interfaces;
standard PoE/ 5 VDC.

  • 40 years of Trust
  • Free Delivery
  • Free Returns
  • Expert Tech Support
View full details
Hikvision DS-KP6000-HE1 | SIP Phone
Login to View Price

Specifications

  • Operating system: Embedded Linux operation system
  • ROM: 16 MB
  • RAM: 64 MB
  • Screen size: 2.3-inch
  • Operation method: Physical keys
  • Type: Dot-matrix display screen
  • Resolution: 128x48
  • Audio input: HD voice microphone; HAC handset
  • Audio compression standard: Narrowband Codec: G.711a/u, G.723.1, G.726, G.729A/B, iLBC Wideband Codec: G.722, Opus
  • Audio output: HD voice speaker (handset/hands-free, 0 ~ 7KHz frequency response)
  • Audio quality: Full-duplex Acoustic Echo Canceller (AEC) / Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) / Background Noise Estimation (BNE) / Noise Reduction (NR) / Automatic Gain Control (AGC)
  • Volume adjustment: Adjustable
  • Communication Lines: 4 SIP Lines
  • Contact capacity: Local phonebook (1000 entries) Remote phonebook (XML/LDAP, 1000 entries)
  • Call log capacity: In/Out/Missed, 600 entries
  • Communication protocol: SIP2.0 over UDP/TCP/TLS RTP/RTCP/SRTP STUN DHCP IPv6 LLDP PPPoE L2TP OpenVPN SNTP FTP/TFTP HTTP/HTTPS TR-069 AES128 & AES256
  • Wired network: 10/100 Mbps self-adaptive, dual bridged port for PC bypass
  • Wi-Fi standard: /
  • Network interface: 2 RJ-45 10/100 Mbps self-adaptive: Network x1, PC x1 (Bridged to Network)
  • Power supply input: DC power input
  • Communication interface: 2 RJ-9 ：handset x1, headset x1
  • Button: 33 physical keys, including: 4 Soft-keys; 9 function keys (Hold/Transfer/Voice message/Conference/Phonebook /MWI/Headset/Redial/Hands-free) ; 4 Navigation keys; 1 OK key; 12 Standard Phone Digits keys; 3 Volume Control keys (Up/Down/Mute (Microphone))
  • Installation: Desktop stand Wall mounting (optional)
  • Indicator: Red: calling and message waiting
  • Working temperature: 0 °C to 45 °C (32 °F to 113 °F)
  • Working humidity: 10% to 95% (no-condensing)
  • Dimensions: Desktop Stand (45°): 169x203.6x172.7 mm ; Desktop Stand (50°): 169x194x181 mm ; Wall mountable: 169x113.4x207.6 mm
  • Power supply: IEEE802.3af, Standard PoE,5 VDC, 0.6 A
  • Application environment: Indoor
  • Power consumption: Power Consumption(Adapter): 0.8~1.29W Power Consumption(PoE): 1.25~1.86W
  • Language: English, Simplified Chinese, Traditional Chinese, Russian, Italian, French, German. Hebrew, Spanish, Catalan, Basque, Galician, Turkish, Hungarian, Slovenian, Czech, Korean, Dutch, Ukrainian, Portuguese, Polish

System parameters
  • Operating system: Embedded Linux operation system
  • ROM: 16 MB
  • RAM: 64 MB

Display parameters
  • Screen size: 2.3-inch
  • Operation method: Physical keys
  • Type: Dot-matrix display screen
  • Resolution: 128x48

Audio parameters
  • Audio input: HD voice microphone; HAC handset
  • Audio compression standard: Narrowband Codec: G.711a/u, G.723.1, G.726, G.729A/B, iLBC Wideband Codec: G.722, Opus
  • Audio output: HD voice speaker (handset/hands-free, 0 ~ 7KHz frequency response)
  • Audio quality: Full-duplex Acoustic Echo Canceller (AEC) / Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) / Background Noise Estimation (BNE) / Noise Reduction (NR) / Automatic Gain Control (AGC)
  • Volume adjustment: Adjustable

Capacity
  • Communication Lines: 4 SIP Lines
  • Contact capacity: Local phonebook (1000 entries) Remote phonebook (XML/LDAP, 1000 entries)
  • Call log capacity: In/Out/Missed, 600 entries

Network parameters
  • Communication protocol: SIP2.0 over UDP/TCP/TLS RTP/RTCP/SRTP STUN DHCP IPv6 LLDP PPPoE L2TP OpenVPN SNTP FTP/TFTP HTTP/HTTPS TR-069 AES128 & AES256
  • Wired network: 10/100 Mbps self-adaptive, dual bridged port for PC bypass
  • Wi-Fi standard: /

Device interfaces
  • Network interface: 2 RJ-45 10/100 Mbps self-adaptive: Network x1, PC x1 (Bridged to Network)
  • Power supply input: DC power input
  • Communication interface: 2 RJ-9 ：handset x1, headset x1

General
  • Button: 33 physical keys, including: 4 Soft-keys; 9 function keys (Hold/Transfer/Voice message/Conference/Phonebook /MWI/Headset/Redial/Hands-free) ; 4 Navigation keys; 1 OK key; 12 Standard Phone Digits keys; 3 Volume Control keys (Up/Down/Mute (Microphone))
  • Installation: Desktop stand Wall mounting (optional)
  • Indicator: Red: calling and message waiting
  • Working temperature: 0 °C to 45 °C (32 °F to 113 °F)
  • Working humidity: 10% to 95% (no-condensing)
  • Dimensions: Desktop Stand (45°): 169x203.6x172.7 mm ; Desktop Stand (50°): 169x194x181 mm ; Wall mountable: 169x113.4x207.6 mm
  • Power supply: IEEE802.3af, Standard PoE,5 VDC, 0.6 A
  • Application environment: Indoor
  • Power consumption: Power Consumption(Adapter): 0.8~1.29W Power Consumption(PoE): 1.25~1.86W
  • Language: English, Simplified Chinese, Traditional Chinese, Russian, Italian, French, German. Hebrew, Spanish, Catalan, Basque, Galician, Turkish, Hungarian, Slovenian, Czech, Korean, Dutch, Ukrainian, Portuguese, Polish
