HiLook IPC-C320HA-D/W(W)(2.8mm) Specialist Camera | 2MP |
HiLook IPC-C320HA-D/W(W)(2.8mm) Specialist Camera | 2MP |
- IP CCTV
- 2 MP
- Fixed Lens
1/2.8" Progressive Scan CMOS; H.265+/H.265/H.264+/H.264/MJPEG; Color:0 lux with IR; 25Fps/30fps(1920×1080); 2 streams; DWDR; 3D DNR; ICR; EXIR, up to 10m; support AI human body detection; support on-board storage up to 512GB(SD card slot), Hik-Connect cloud service, Build-in microphone and speaker; Built-in 2.4G Wi-Fi, 802.11b/g/n; 12VDC & PoE power supply.
*SD card is not included.
*Power supplier is not included
-
40 years of Trust
-
Free Delivery
-
Free Returns
-
Expert Tech Support
HiLook IPC-C320HA-D/W(W)(2.8mm) Specialist Camera | 2MP |
Specifications
- Image Sensor: 1/3" Progressive Scan CMOS
- Max. Resolution: 1920 × 1080
- Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
- Shutter Time: 1/3 s to 1/100,000 s
- Day & Night: IR cut filter
- Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
- Focal Length & FOV: 2.8 mm, horizontal FOV 92°, vertical FOV 50°, diagonal FOV 110° 4 mm, horizontal FOV 75°, vertical FOV 41°, diagonal FOV 89°
- Aperture: F1.6
- Lens Mount: M12
- DORI: 2.8 mm: D: 38.6 m, O: 15.3 m, R: 7.7 m, I: 3.9 m 4 mm: D: 54.8 m, O: 21.7 m, R: 11.0 m, I: 5.5 m
- Supplement Light Type: IR
- Supplement Light Range: Up to 10 m
- IR Wavelength: 850 nm
- Smart Supplement Light: Yes
- Main Stream: 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 768 × 432) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 768 × 432)
- Sub-Stream: 50 Hz: 25 fps (768 × 432, 512 × 288) 60 Hz: 30 fps (768 × 432, 512 × 288)
- Video Compression: Main stream: H.265/H.264 Sub-stream: H.265/H.264
- Video Bit Rate: Up to 1 M bps
- H.264 Type: Baseline Profile/Main Profile/High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR/VBR
- Environment Noise Filtering: Yes
- Audio Sampling Rate: 8 kHz/16kHz
- Audio Compression: G.711/AAC-LC
- Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 to 64 Kbps (AAC-LC)
- Simultaneous Live View: Up to 4 channels
- API: ONVIF, SDK
- Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, UPnP, IGMP, QoS, IPv4, UDP, Bonjour, SSL/TLS
- User/Host: Administrator
- Security: Password protection, HTTPS encryption, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE for Open Network Video Interface
- Client: iVMS-4200, HiLookVision, Hik-Partner-Pro
- Encryption Mode: WPA-PSK/WPA2-PSK
- Wi-Fi Protocol: IEEE 802.11b, 802.11g, 802.11n
- Frequency Range: 2.412 GHz to 2.472 GHz
- Channel Bandwidth: 20 MHz
- Modulation: 802.11b: CCK, QPSK, BPSK 802.11g: OFDM 802.11n: OFDM
- Wireless Range: Up to 50 m (The performance varies based on actual environment)
- Transfer Rate: 11b: up to 54 Mbps, 11g: up to 54 Mbps, 11n: up to 150 Mbps
- Wide Dynamic Range (WDR): Digital WDR
- Privacy Mask: 4 programmable polygon privacy masks
- Day/Night Switch: Day, Night, Auto, Schedule
- Image Parameters Switch: Yes
- Image Settings: Saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software
- Built-in Microphone: Yes, 1 built-in microphone
- Built-in Speaker: Yes, 1 built-in speaker
- On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
- Reset Key: Yes
- Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
- Basic Event: Motion detection (support alarm triggering by specified target types (human)), exception
- Linkage: Upload to memory card, notify surveillance center, trigger capture, audible warning, auto-tracking lite
- Power: 12 VDC, 0.4 A, max. 4.9 W, Ø2.0 mm coaxial power plug, PoE: IEEE 802.3af, Class 3
- General Function: Heartbeat, Mirror
- Storage Conditions: -10 °C to 45 °C (14 °F to 113 °F). Humidity 95% or less (non-condensing)
- Startup and Operating Conditions: -10 °C to 45 °C (14 °F to 113 °F). Humidity 95% or less (non-condensing)
- Material: Plastic
- Dimension: 102.9 mm × 65.2 mm × 32.6 mm (4.1" × 2.6" × 1.3")
- Package Dimension: 150 mm × 125 mm × 99 mm (5.9" × 4.9" × 3.9")
- Weight: Approx. 120 g (0.3 lb.)
- With Package Weight: Approx. 430 g (0.9 lb.)
- EMC: CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014)
- RF: CE-RED (EN 301489-1 V2.1.1(BT or 2.4G); EN 301489-17 V3.1.1(BT or 2.4G); EN 300328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G))
- Safety: CE-LVD (EN 62368-1:2014/A11:2017)
- Environment: CE-RoHS (2011/65/EU) WEEE (2012/19/EU)
