HiLook NS-0318P-130(B)
HiLook NS-0318P-130(B)
- Switches
- Network Switches
- Value Series
L2, Unmanaged, 16 100M PoE port, 1 1000M RJ45, 1 1000M SFP, 802.3af/at, PoE power budget 130W, "Extend" Mode: Port 9-16, max. 250m long distance transmission;
-
40 years of Trust
-
Free Delivery
-
Free Returns
-
Expert Tech Support
HiLook NS-0318P-130(B)
Specifications
- Shell: Metal material
- Operating temperature: -10 °C to 55 °C (14 °F to 131 °F)
- Storage temperature: -40 °C to 85 °C (-40 °F to 185 °F)
- Power supply: 100 to 240 VAC, 50/60 Hz, Max. 2.5 A
- Storage humidity: 5% to 95% (no condensation)
- Net weight: 1.8 kg (4.0 lb)
- Gross weight: 2.58 kg (5.69 lb)
- Dimension (L × H × D): 266 mm × 44.5 mm × 220.8 mm (10.5” × 1.8” × 8.7”)
- Operating humidity: 5% to 95% (no condensation)
- Power consumption in idle: 20 W
- Port number: 16 × 100 Mbps PoE ports, 1 × 1000 Mbps RJ45 port, and 1 × 1000 Mbps SFP fiber optical port
- Port type: RJ45 port, full duplex, MDI/MDI-X adaptive
- Standard: IEEE 802.3, IEEE 802.3u, IEEE 802.3x
- Forwarding mode: Store-and-forward switching
- Working mode: Standard mode (default); Extend mode
- MAC address table: 4 K
- Switching capacity: 7.2 Gbps
- Packet forwarding rate: 5.356 Mpps
- Internal cache: 2.75 Mbits
- High priority ports: Ports 1 to 8
- Ports for long-distance transmission: Ports 9 to 16
- PoE standard: IEEE 802.3af, IEEE 802.3at
- PoE power pin: Ports for long-distance transmission (9-16) support 8-core power supply, Ethernet cable 1/2/3/6 and 4/5/7/8 provide simultaneous power supply. Ports for close-range transmission (1-8) support 4-core power supply, Ethernet cable 1/2/3/6 provide power supply.
- PoE port: Ports 1 to 16
- Max. port power: 30 W
- PoE power budget: 130 W
- Max. power consumption: 150 W
