Reyee Smart CCTV Switch-PoE | RG-ES220GS-P
Reyee Smart CCTV Switch-PoE | RG-ES220GS-P
- Network Switches
- Managed PoE Switches
- 16 Port
20-Port gigabit cloud managed PoE switch with 16 PoE+ ports, 2 SFP ports
Key Features
- 20-Port gigabit cloud managed PoE switch with 16 PoE+ ports
- 2 SFP ports
Model: RG-ES220GS-P
-
Free Delivery
-
Free Returns
-
Expert Tech Support
Reyee Smart CCTV Switch-PoE | RG-ES220GS-P
Specifications
- Total number of RJ45 ports: 18
- Total number of optical ports: 2
- Number of 1GE SFP ports: 2
- Number of 10/100/1000BASE-T ports: 18
- Number of PoE Out ports: 16
- Number of PoE/PoE+ Out ports: 16
- PoE budget: 250 W
- PoE power pins: 1–2 (+), 3–6 (-)
- Operating temperature: 0°C to 40°C (32°F to 104°F)
- PoE watchdog: Yes
- Port isolation: Yes
- Warranty: 3 years
- Forwarding rate: 29.7 Mpps
- Switching capacity: 40 Gbps(bit/s)
- MTBF: 200,000 hours
- Altitude: –500 m to +5,000 m (–1,640.42 ft. to +16,404.20 ft.)
- Surge protection: Service port: ±4 kV for common mode Power connector: ±6 kV for common mode and ±6 kV for differential mode
- Safety compliance: EN 62368-1 IEC 62368-1
- Maximum number of VLANs: 16
- Maximum number of MAC address entries: 8000
- Cable test: Yes
- DHCP snooping: Yes
- Recommended camera limit: 200W H265: 80 400W H265: 40
